Folding Crane Yankee 1ton 'kd' Type

Please note - colour is blue - not red as shown in picture.

super economy model delivered in knock down form for reduced freight cost. fast folding model provides easy storage and transportation. heavy-duty castors. weighs only 74kg and is perfect for mobile or workshop use. side pump access with removable handle.

lifting cap in position 1: 1000kg

lifting cap in position 2: 750kg

lifting cap in position 3: 500kg

lifting cap in position 4: 250kg

maximum lift ht at minimum jib extn: 1855mm

maximum lift ht at maximum jib extn: 1990mm

length of jib position 1: 893mm

length of jib position 2: 983mm

length of jib position 3: 1073mm

length of jib position 4: 1163mm

height of frame: 147mm

length of frame: 1518mm

overall height: 1550mm

maximum width of frame: 962mm

width inside frame: 862mm

distance between centres of rear wheels: 685mm

weight: 74kg
